224 Frequency Synthesizer Fault Finding TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Task 31 —
Check Transmit-
Receive Switch
If no frequency is detected in the check of the VCO, first check that the
transmit-receive switch is functioning correctly.
1. Resolder R542 in position (see Figure 9.13).
2. Remove the
VCO BOT can.
3. Enter the CCTM command 335 0 to switch on the supply to the
RX
port.
4. Measure the voltage at pin 2 of D5004 (see Figure 9.14). (Some RF
noise might be observed.) The voltage should be:
5. Enter the CCTM command 335 1 to switch off the supply.
6. Again measure the voltage at pin 2 of D5004.
7. If the voltages measured in Step 4 and Step 6 are correct, go to
Step 8. If they are not, the switching network is suspect; go to
Tas k 32
.
8. Enter the CCTM command 335 1 to switch on the supply to the
TX
port.
9. Measure the voltage at pin 1 of D5004 (see Figure 9.14). (Some RF
noise might be observed.) The voltage should be:
10. Enter the CCTM command 335 0 to switch off the supply.
11. Again measure the voltage at pin 1 of D5004.
12. If the voltages measured in Step 9 and Step 11 are correct, go to
Tas k 33
. If they are not, the switching network is suspect; go to
Tas k 32
.
pin 2 of D5004: 5.0 ± 0.3 V DC (after entry of CCTM 335 0)
pin 2 of D5004: 0 V DC (after entry of CCTM 335 1)
pin 1 of D5004: 5.0 ± 0.3 V DC (after entry of CCTM 335 1)
pin 1 of D5004: 2.1 ± 0.4 V DC (after entry of CCTM 335 0)
