Tait TM8110 Service Manual

238 Frequency Synthesizer Fault Finding TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
4. Replace all cans.
5. Repeat Ta s k 4 0
to confirm the removal of the fault. If the repair
failed, replace the board and go to “Final Tasks” on page 157.
Task 42 —
CODEC 2 Circuitry
If the CCTM checks indicate a fault in the CODEC 2 circuitry or with the
digital signals to and from the circuitry, rectify the fault as follows:
1. Most of the CODEC 2 circuitry is situated under the
CDC TOP can.
If not already done, remove the
CDC TOP can.
2. Check the following digital signals at IC205 (see Figure 9.16):
■ pin 10 : DIG CDC2 LRCK
■ pin 12 : DIG CDC2 SCLK
■ pin 8 : CDC2 DIG SDTO
■ pin 9 : DIG CDC2 SDTI.
These signals to and from the digital board should all be active:
3. If the digital signals are correct, the CODEC 2 circuitry is suspect;
go to Step 6. If they are not, go to Step 4.
4. If any or all digital signals are missing, check the connections between
IC205 and the digital board (see Figure 9.16).
5. If there are faults such as open circuits in the connections, repair the
circuitry and repeat Ta sk 4 0
.
If the connections are not faulty, then the digital board is faulty.
Replace the board and go to “Final Tasks” on page 157.
6. The CODEC 2 circuitry comprises IC205 and associated components
under the
CDC TOP can (see Figure 9.16) as well as R246 under the
CDC BOT can (see Figure 7.3 on page 168). Locate the fault.
7. Repair the circuitry. Note that, if the circuitry is functioning properly,
probing the
TP501 test point (see Figure 9.17) during power-up
will show a five-step staircase signal followed by a random nine-step
staircase signal — this is the expected power-up auto-calibration
sequence.
8. Confirm the removal of the fault, and go to Step 9. If the repair
failed, replace the board and go to “Final Tasks” on page 157.
9. Replace all cans.
10. Repeat Ta s k 40
to confirm the removal of the fault. If the repair
failed, replace the board and go to “Final Tasks” on page 157.
digital signals: 3.3 ± 0.3 V
