TM8100/TM8200 Service Manual Transmitter Fault Finding (25W) 345
© Tait Electronics Limited June 2006
Figure 12.8 Test points and components of the shaping filter
DIRC TOP CAN
IF TOP CAN
VCO TOP CAN (UHF ONLY)
SET PWR
TEST POINT
FWD PWR
TEST POINT
PWR TEST POINT FIN1 TEST POINT FIN2 TEST POINT
DRV TEST POINT
