346 Transmitter Fault Finding (25W) TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Figure 12.9 PA circuitry under the PAF TOP can (VHF shown)
D301
PAF TOP
CIRCUITRY BETWEEN
IC301 AND PAs
VIA TO GATE OF Q309
VIA TO GATE OF Q310
Q310
Q309
D1 BAND
VIA TO PIN 14 OF 1C301
VIA TO PIN 8 OF IC301
