390 CODEC and Audio Fault Finding TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Task 7 —
Check ITF RX BEEP IN
Input Signal
If the output of the voice-band CODEC is not correct, check the
ITF RX BEEP IN signal.
1. If not already done, remove the
CDC BOT can.
2. Check the signal at the junction of R218 and IC204
(see Figure 13.4). The signal should be:
3. If the signal is correct, go to Step 4. If it is not, either CODEC 1
(IC204) or the digital board is faulty; replace the board and go to
“Final Tasks” on page 157.
4. Check for continuity between the
TP200 test point and IC204 via
R214, R215 (see Figure 13.2) and R218 (see Figure 13.4).
Repair any fault; if necessary, replace R214, R215 or R218.
5. Confirm the removal of the fault and go to “Final Tasks” on
page 157. If the repair failed or the fault could not be found, replace
the board and go to “Final Tasks” on page 157.
junction of R218 and IC204: sine wave about 1V
pp
with 1.2V DC offset
