TM8100/TM8200 Service Manual CODEC and Audio Fault Finding 403
© Tait Electronics Limited June 2006
Task 16 —
Check CODEC 2
Device
If the DC offset measured in Task 15 is incorrect but there is no fault with
the auxiliary connector, check the CODEC 2 device.
1. Remove the
CDC TOP can.
2. Check the voltage at both ends of R241 (see Figure 13.10):
3. If the voltages are correct, go to Step 4. If they are not, go to Step 6.
4. Check for and repair any soldering faults around IC205, or else
replace IC205 (see Figure 13.10).
5. Confirm the removal of the fault and go to “Final Tasks” on
page 157. If the repair failed, replace the board and go to “Final
Tasks” on page 157.
6. Remove R241.
7. Check the voltage at pin 3 of IC205 (see Figure 13.10):
8. If the above voltage is correct, go to Step 9. If it is not, replace the
board and go to “Final Tasks” on page 157.
9. Check for and repair any soldering faults around R241 and IC205
(see Figure 13.10).
10. Confirm the removal of the fault and go to “Final Tasks” on
page 157. If the repair failed, replace the board and go to “Final
Tasks” on page 157.
R241: 1.5V DC at both ends
pin 3 of IC205: 1.5V DC
