Tait TM9300 User Manual

68 Operating in conventional mode
Sending a text message
1 When you have chosen or entered a message,
press Options and the Text options menu opens.
2 In the Text options menu, scroll through the list of
options until the choice you want appears.
3 Select Send and press Select.
4 If an address book is configured, you can select to
either dial a number or show the address book.
Otherwise a preset list of radios will appear.
The call details appear on the display.
Receiving a text message
If the radio is programmed for call queuing, incoming
text messages are added to the queue. For more
information, see "Checking the queue" on page 69.
Press Options and select whether to reply, call or
delete.
Your radio may be programmed to automatically view
text messages on receipt.
If the radio is not programmed for call queuing,
incoming text messages will not be stored or
displayed.
SelectBack
Text options
Send
Cancel sending
Send using
Dialed number
Address book
Back Select
Call alert
Richard
John
Send toCancel

Tait TM9300 Specifications

General

Modulation	FM, 4FSK (DMR)
IP Rating	IP54
GPS	Optional
Bluetooth	Optional
Frequency Range	450-520 MHz
Channel Spacing	12.5 / 25 kHz
Operating Modes	Analog FM
Dimensions	160 x 60 x 40 mm (without antenna)
Weight	1.6 kg (3.53 lbs)
Operating Temperature	-30°C to +60°C (-22°F to +140°F)
Power Output	5 W, 25 W, 50 W
RF Output Power	5 W, 25 W, 50 W
