Tait TM9300 User Manual

94 Operating in trunked mode
Selecting a zone
1 Press Menu and select Set zone.
(Depending on how your radio is programmed, you
may be able to use the scroll keys or left selection
key to select a zone.)
2 In the Set zone menu, scroll through the list of
zones until the zone you want appears.
3 Press Select.
4 Check that orange LED is glowing and the network
icon appears on the display.
Selecting a workgroup
1 Press Menu and select Set workgroup.
(Depending on how your radio is programmed, you
may be able to use the scroll keys or left selection
key to select a workgroup.)
2 In the Set workgroup menu, scroll through the list
of workgroups until the workgroup you want
appears.
3 Press Select.
4 Check that orange LED is glowing and the network
icon appears on the display.
Making a call to a workgroup
Different types of calls may be associated with your
workgroups. These calls can be any types of calls.
To make a call to a workgroup:
SelectBack
Main menu
Set zone
Set workgroup
SelectBack
Main menu
Set workgroup
Go to homegroup

Tait TM9300 Specifications

General

Modulation	FM, 4FSK (DMR)
IP Rating	IP54
GPS	Optional
Bluetooth	Optional
Frequency Range	450-520 MHz
Channel Spacing	12.5 / 25 kHz
Operating Modes	Analog FM
Dimensions	160 x 60 x 40 mm (without antenna)
Weight	1.6 kg (3.53 lbs)
Operating Temperature	-30°C to +60°C (-22°F to +140°F)
Power Output	5 W, 25 W, 50 W
RF Output Power	5 W, 25 W, 50 W
