Pump Connection:
MOBIUS Water Heater Main Multi System Controller will be maintaining setting temperature inside
storage tank water with automatically T-M1 ON/OFF Mode.
Circulation Pump between T-M1 system and Storage has to be ON (running) 24- Hour, it will maintain
set temperature.
Final Check of the Multi-System: From MOBIUS Water Heater Model T-M1 Computer Board, it has
a jump cable for Single mode or Multi mode. To switch to Multi mode, this jump cable has to be
removed from the T-M1 computer board permanently, but please keep this jump connector safety
stored for future maintenance (this jumper is located behind the “do not remove” label.
Pull out jump cable for Store for
activates power port.
Needs power relay for using this
application
