223
OPTIONS
Auxiliary Pedal
WARNING
When not using the pedal, set the pedal
lock to the locked position. Stepping on
a pedal accidentally when it is not locked
may lead to unexpected accidents.
This pedal controls the flow of the oil in the
auxiliary hydraulic circuit.
(A) .... Hydraulic oil flows to left auxiliary
hose
(B) .... Hydraulic oil flows to right auxiliary
hose
¡When the safety lock lever is set to the
lock position, this pedal is locked.
Refer to page 52 “Auxiliary Hydraulic
Lines”.
K3L016
K3L017
A
B
To Next Page
