Takeuchi TB135 User Manual

53
CONTROLS
2. Stop the engine and open the selector
valve (1) on the machine body.
(The residual pressure is released from
the (b) port line.)
When equipped with accumulator (option):
Refer to page 232 “Accumulator”.
Selector valve
O: Open .......When using a hydraulic
breaker (1-way flow)
S: Closed..... When using a reversible
attachment (2-way flow)
Change the direction of the hydraulic oil flow
by opening or closing the selector valve on
the machine body.
Accessories
External Power Sockets (for EU)
IMPORTANT: Only use applicable electric
products with these sockets.
for Beacon
Use these sockets as an external power
supply. When using these sockets, be
careful not to exceed 12V/10A.
To use, raise the cap (1).
1 - way
2 - way
1
1
O
S
G4D007E
C4C0281
1
1
N0C008
