1. Open the front window and stow it in the ceiling.
2. Grasp the protruding parts (4) on the left and
right with your fingers and slowly lift the lower
front window off.
3. Hold the glass firmly, place the lower front
window through the guides (5) at the rear, then
set it on the supports (6) and fasten it in place.
Lower Front Window
Removing
Doors and Covers
Side Window
1. Grasp the catch (7), unlock it and open the side
window.
2. To close the side window, close it until a click is
heard.
Tool Box
1. After using tools, store them back in the tool box.
Emergency Exit
Front window (excluding machines with a front
guard)
If you should become trapped inside the cab,
open the front window to get out.
Emergency hammer (optional)
An emergency hammer is installed to be used
to escape from the cab in an emergency. When
escaping, break the windows with the hammer.
Applicable machine models
175400373 or later
