55
CONTROLS
Throttle Buttons
The engine speed increases and decreases
continuously while these buttons are pressed.
When the button is released, the engine
speed is set to the speed at the time the
button is released.
Engine speed increases
Engine speed decreases
When the throttle buttons are operated and
the engine speed is at a point between the
different modes, the lamps on both sides light.
When the speed is changing, only the lamp
for the nearest engine speed lights.
Switches
L: This mode is always set when the engine
is started.
Use it for light and very light
operations.
FC: Use this mode for light operations and
leveling operations which do not require
speed. Using this mode reduces fuel
consumption and noise.
H: Use this mode for general digging and
loading operations requiring power and
speed.
Changing the engine revolutions
The engine revolutions can be changed in the
L and FC modes.
Do the following steps to change.
1. Start the engine.
2. Press and hold the L or FC mode button
for two seconds or more to cause the
mode lamp start flashing on the instrument
cluster.
3. Press the throttle button while pressing
down the L or FC mode button.
(Each pressing increases/decreases the
revolutions by 10 revolutions)
Engine revolutions increases
Engine revolutions decreases
4. Listen to the engine sound and release
the button when you hear the desired
revolution sound.
To return to the initially set revolutions, press
and hold the L or FC mode button for five
seconds or more.
