Takeuchi TB216 Workshop Manual

DISASSEMBLY AND ASSEMBLY
UPPER FRAME
7
4
UPPER FRAME 4E0AX00
Removing the canopy
1. Remove the battery ground cable from the battery
terminal.
2. Disconnect the electrical wiring from the canopy.
3. Take out the mounting bolts.
Bolt: 135 N·m (99.6 ft-lb)
4. Suspend the canopy and then remove it.
Canopy: 48 kg (105 lb)

Takeuchi TB216 Specifications

General

Engine Make	Yanmar
Engine Model	3TNV70
Transport Width	980 mm
Bucket Capacity	0.04 m³
Maximum Reach	4, 040 mm
Max Reach at Ground Level	3, 980 mm
