Takeuchi TB216 Workshop Manual

DISASSEMBLY AND ASSEMBLY
DRIVE SYSTEM
8
4
DRIVE SYSTEM 4B0AX00
Removing the fuel tank
1. Remove the canopy.
2. Remove the covers from the perimeter around the
tank.
3. Loosen the drain plug (9), and let the fuel drain out.
• Fuel tank capacity: 22 L (5.8 US·gal)
4. Disconnect the fuel hoses from the fuel tank, sedi-
menter, and fuel pump.
5. Take out the bolts holding the fuel tank (1) in place,
and remove the fuel tank (1).
Bolt: 22.6 N·m (16.7 ft-lb)
Installing the fuel tank
For installation, follow the same procedures as for remov-
al but in the reverse order.

Takeuchi TB216 Specifications

General

Engine Make	Yanmar
Engine Model	3TNV70
Transport Width	980 mm
Bucket Capacity	0.04 m³
Maximum Reach	4, 040 mm
Max Reach at Ground Level	3, 980 mm
