Takeuchi TB216 Workshop Manual

SERVICE DATA
SPECIFICATION TABLES
2
2
SPECIFICATION TABLES 2B0AX003
Dimensions of base machine
Overall length of base
machine
215000003 to
215002407
Rubber
crawler
mm (in.) 1560 (61.4)
Steel
crawler
mm (in.) 1565 (61.6)
from
215002408
Rubber
crawler
mm (in.) 1570 (61.8)
Steel
crawler
mm (in.) 1565 (61.6)
Overall width of base
machine
During normal operation mm (in.) 1300 (51.2)
Track retracted mm (in.) 980 (38.6)
Upper structure overall width mm (in.) 980 (38.6)
Upper structure overall
width
Left mm (in.) 490 (19.3)
Right mm (in.) 490 (19.3)
Cab overall width mm (in.) -
Overall height of base
machine
Rubber crawler mm (in.) 2345 (92.3)
Steel crawler mm (in.) 2350 (92.5)
Swing radius mm (in.) 720 (28.3)
Upper structure rearmost distance from axis of rotation mm (in.) 720 (28.3)
Clearance height under
upper structure
Rubber crawler mm (in.) 460 (18.1)
Steel crawler mm (in.) 450 (17.7)
Crawler base
215000003 to
215002407
Rubber
crawler
mm (in.) 1155 (45.5)
Steel
crawler
mm (in.) 1135 (44.6)
from
215002408
Rubber
crawler
mm (in.) 1205 (47.4)
Steel
crawler
mm (in.) 1180 (46.5)
Crawler overall length
215000003 to
215002407
Rubber
crawler
mm (in.) 1520 (59.8)
Steel
crawler
mm (in.) 1500 (59.1)
from
215002408
Rubber
crawler
mm (in.) 1570 (61.8)
Steel
crawler
mm (in.) 1550 (61)
Undercarriage overall
width
During normal operation mm (in.) 1300 (51.2)
Track retracted mm (in.) 980 (38.6)
Track gauge
During normal operation mm (in.) 1070 (42.1)
Track retracted mm (in.) 750 (29.5)
Track shoe width mm (in.) 230 (9.1)
Ground clearance of
undercarriage
Rubber crawler mm (in.) 205 (8.1)
Steel crawler mm (in.) 195 (7.7)

Takeuchi TB216 Specifications

General

Engine Make	Yanmar
Engine Model	3TNV70
Transport Width	980 mm
Bucket Capacity	0.04 m³
Maximum Reach	4, 040 mm
Max Reach at Ground Level	3, 980 mm
