40
CONTROLS
Doors and Covers
Side Window (Cab)
1.Grasp the catch (7), unlock it and open
the side window.
2.To close the side window, close it until a
click is heard.
7
C4C007
Tool Case
Opening
1.Remove the wing bolt (1) and turn the cover
(2).
Closing
1.Return the cover (2) and tighten the wing
bolt (1).
F4B007
2
1
