70
OPERATION
Machine Operation
Traveling Forward and Backward
1.Pull the throttle lever and increase the
engine speed.
: Release : Lock on
2.Set the safety lock lever to the released
position.
3.Fold the hoe attachment and lower it to 30
to 40 cm(12 to 16 in.) above the ground.
4.Lift the dozer blade.
Operating the Travel Levers
¡Never allow anyone to enter the
slewing (swing) radius and machine
path.
¡Signal your intention to move by
sounding the horn.
¡There are blind spots to the rear of the
machine.
If necessary,swing the cab around
before backing up to check that the
area is safe and clear.
¡Before operating the travel levers,
check to make sure that the dozer blade
is to the front of the operator's seat.
BE AWARE that when the dozer blade
is to the rear of the operator's seat, the
travel levers operate in the opposite
direction to when the dozer blade is in
the front.
¡Remove any obstacles in the
machine’s path.
WARNING
Dozer blade
30~40cm
E4D014
C4D004
S2D007
To Next Page
