Takeuchi TB53FR Workshop Manual

GENERAL
I-14TB53FR
Joints for Piping
Joints for Piping (O-ring Seal Type)
1/8
1/4
3/8
1/2
3/4
1
Nominal Thread
Diameter
(R)
Torque
Steel Cast Steel
N·m ft-lb N·m ft-lb
11.8 ±1.2
29.4 ±2.9
53.9 ±5.4
88.3 ±8.8
147.1 ±14.7
196.1 ±19.2
8.7 ±0.8
21.7 ±2.1
39.8 ±3.9
65.1 ±6.4
108.5 ±10.7
144.7 ±14.3
10.8 ±1.1
24.5 ±2.5
49 ±4.9
73.5 ±7.4
127.5 ±12.7
171.6 ±17.2
8.0 ±0.7
18.1 ±1.7
36.2 ±3.5
54.3 ±5.3
94.1 ±9.3
126.6 ±12.5
Nominal Thread
Diameter
(G)
Torque
N·m ft-lb
1/8
1/4
3/8
1/2
3/4
1
1-1/4
1-1/2
19.6 ±2.0
34.3 ±4.9
53.9 ±4.9
63.7 ±4.9
93.2 ±4.9
107.9 ±9.8
117.7 ±9.8
137.3 ±9.8
14.5 ±1.4
25.3 ±3.5
39.8 ±3.5
47.0 ±3.5
68.7 ±3.5
79.5 ±7.2
86.8 ±7.2
101.2 ±7.2
Nominal Thread
Diameter
(UNF)
Torque
N·m
ft-lb
7/16–20
1/2–20
9/16–18
3/4–16
1-1/16–12
1-5/16–12
1-5/8–12
16.7 ±2.0
22.6 ±2.0
31.4 ±2.9
59.8 ±4.9
102.0 ±5.9
135.3 ±7.8
181.4 ±9.8
12.3 ±1.4
16.6 ±1.4
23.1 ±2.1
44.1 ±3.5
75.2 ±4.4
99.8 ±5.8
133.8 ±7.2
O-RING
