157
SPECIFICATIONS
Operating Range
Units: mm (inches)
Item
Standard Arm Long Arm
Rubber Crawlers
A Max. digging radius 5905 (232.4) 6195 (243.9)
B Max. ground digging radius 5765 (227.0) 6065 (238.7)
C Max. digging depth 3590 (141.3) 3900 (153.5)
D Max. vertical digging depth 2735 (107.7) 3030 (119.2)
E Max. digging height 5320 (209.4) 5490 (216.2)
F Max. dumping height 3710 (146.1) 3885 (152.9)
G Min. dumping height 1515 (59.7) 1125 (44.3)
H Max. vertical digging radius 3885 (153.0) 4075 (160.4)
J Max. raising height 335 (13.2) ←
K Max. lowering depth 320 (12.6) ←
