Takeuchi TB53FR User Manual

181
OPTIONS
Second Auxiliary Hydraulics
Lubricating
If the pedal no longer move smoothly, supply
grease.
1. Remove the lower mount section of the
boot (1) and turn it upwards.
2. Wipe off the old grease.
3. Supply grease to points (A) and (B).
4. Set the boot (1) back as it was.
T7G0271
B
A
B
1
