Takeuchi TL8 User Manual

3-9
OPERATION
OPERATING THE MACHINE
LEVER PATTERN (H) (IF EQUIPPED)
Before starting operation, be sure to check which lever pattern you are going to use.
This manual explains the operation by using the ISO pattern.
Travel Forward (Left track) Travel Forward (Right track)
Travel Reverse (Left track) Travel Reverse (Right track)
Lift Arms Raise Bucket Rollback
Lift Arms Lower Bucket Dump
Lift Arms Float
(Tilt the left control lever to the right)
Lift Arms Float
(Push the left lever to the right and
press the float button)
N Neutral N Neutral
Refer to “Selecting a lever pattern” on page 8-9.

Takeuchi TL8 Specifications

General

Tipping Load	6, 021 lbs
Engine Make	Kubota
Engine Model	V3307-CR-TE4
Rated Operating Capacity	2, 107 lbs
Auxiliary Hydraulics - High Flow	Not available
Gross Power	Not available
