BlinkerBeam™ Radio Operation Guide
8
CONTROLLER STATUS MENU
To access the CONTROLLER STATUS menu, select MAIN MENU>Controller
Status. See Figure 11.
The CONTROLLER STATUS menu displays the device settings but does not
allow adjustments to the settings (See Figures 12-13):
 Timeout: Length of time an activated device stays ON until it turns itself
OFF, ending a signal operation cycle
 BatTemp: Battery Temperature (°F)
 BatVolt: Battery Voltage (mV)
 SolVolt: Solar Voltage (mV)
 SolCurr: Solar Current (mA)
 Serial: 10-digits representing the serial number of the built-in Intelligent
Warning System (IWS) controller
Radio Status Menu
To access the RADIO STATUS menu, select MAIN MENU>Radio Status. See
Figure 14.
RADIO STATUS: To the right of the title is an indicator of the radio’s network
status.
 -TX-: This radio is a transmitter. See Figure 15.
 SYNC’D: This radio is a receiver, and the binding code and hop frequency
have been recognized in the network. See Figure 16.
 NOSYNC: This radio is a receiver, but it has no network connection.
See Figure 17.
TAPCO PN: Identifies the TAPCO radio part number
Radio Fw V identifies the Firmware Version. See Figure 18.
LCD Fw Ver identifies the LCD display board Firmware. See Figure 18.
Bind Code identifies the 8-digit code that matches all other radios in the
network. See Figure 18.
NOTICE
A radio must have the same BindCode (Binding Code) and Hop Seq.
(Hop Channel) as every other radio in the network.
Note: If this radio’s BindCode does not match the BindCode of the
other radios in the network, see Set Binding Code in the Radio
Setup menu or Quick Setup menu.
NetCnt/Size: NetCnt (Network Count) shows all radios in the network. Size
is the maximum number of radios in a network, which is 16. See Figure 19.
Radio Fw PN identifies the Firmware Part Number. See Figure 19.
Hop Seq. (Frequency Hopping Channel) selects which frequency hopping
pattern is used by the network. See Figure 19.
Figure 14
MAIN MENU
3) Radio Setup
4) Legacy Control
5) Site Survey
>
MAIN MENU
2) Radio Status
3) Radio Setup
4) Legacy Control>
MAIN MENU
1) Controller Status
2) Radio Status
3) Radio Setup
4) Legacy Control
5) Site Survey
MAIN MENU
1) Controller Status
2) Radio Status
3) Radio Setup
>
MAIN MENU
0) Quick Setup
1) Controller Status
2) Radio Status
3) Radio Setup
>
>
MAIN MENU
1) Controller Status
2) Radio Status
3) Radio Setup
LCD Screen Icons
Selected and Saved
Saved Value
Selected
>
*
->
1
2
3
4
5
6
Figure 18
RADIO STATUS
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
Net Cnt/Size: #/16
Radio Fw PN:: ######
Hop Seq: #
FCC ID: # ####-######
- - >See Network Table
RADIO STATUS NOSYNC
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS SYNC’D
TAPCO PN: ######
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS -TX-
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS
Net Cnt/Size: #/16
Radio Fw PN:: ######
Hop Seq: #
RADIO STATUS
Radio Fw PN:: ######
Hop Seq: #
Model: #
FCC ID: # ####-######
IC: #
>
RADIO STATUS
FCC ID: # ####-######
IC: #
- - >See Network Table
>
1
2
3
4
5
6
7
8
9
10
11
Figure 19
RADIO STATUS
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
Net Cnt/Size: #/16
Radio Fw PN:: ######
Hop Seq: #
FCC ID: # ####-######
- - >See Network Table
RADIO STATUS NOSYNC
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS SYNC’D
TAPCO PN: ######
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS -TX-
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS
Net Cnt/Size: #/16
Radio Fw PN:: ######
Hop Seq: #
RADIO STATUS
Radio Fw PN:: ######
Hop Seq: #
Model: #
FCC ID: # ####-######
IC: #
>
RADIO STATUS
FCC ID: # ####-######
IC: #
- - >See Network Table
>
1
2
3
4
5
6
7
8
9
10
11
Figure 15
RADIO STATUS
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
Net Cnt/Size: #/16
Radio Fw PN:: ######
Hop Seq: #
FCC ID: # ####-######
- - >See Network Table
RADIO STATUS NOSYNC
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS SYNC’D
TAPCO PN: ######
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS -TX-
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS
Net Cnt/Size: #/16
Radio Fw PN:: ######
Hop Seq: #
RADIO STATUS
Radio Fw PN:: ######
Hop Seq: #
Model: #
FCC ID: # ####-######
IC: #
>
RADIO STATUS
FCC ID: # ####-######
IC: #
- - >See Network Table
>
1
2
3
4
5
6
7
8
9
10
11
Figure 16
RADIO STATUS
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
Net Cnt/Size: #/16
Radio Fw PN:: ######
Hop Seq: #
FCC ID: # ####-######
- - >See Network Table
RADIO STATUS NOSYNC
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS SYNC’D
TAPCO PN: ######
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS -TX-
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS
Net Cnt/Size: #/16
Radio Fw PN:: ######
Hop Seq: #
RADIO STATUS
Radio Fw PN:: ######
Hop Seq: #
Model: #
FCC ID: # ####-######
IC: #
>
RADIO STATUS
FCC ID: # ####-######
IC: #
- - >See Network Table
>
1
2
3
4
5
6
7
8
9
10
11
Figure 17
RADIO STATUS
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
Net Cnt/Size: #/16
Radio Fw PN:: ######
Hop Seq: #
FCC ID: # ####-######
- - >See Network Table
RADIO STATUS NOSYNC
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS SYNC’D
TAPCO PN: ######
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS -TX-
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS
Radio Fw V: ##.##.###
LCD Fw V: ##.##.###
BindCode: ##########
RADIO STATUS
Net Cnt/Size: #/16
Radio Fw PN:: ######
Hop Seq: #
RADIO STATUS
Radio Fw PN:: ######
Hop Seq: #
Model: #
FCC ID: # ####-######
IC: #
>
RADIO STATUS
FCC ID: # ####-######
IC: #
- - >See Network Table
>
1
2
3
4
5
6
7
8
9
10
11
Figure 12
CONTROLLER STATUS
Timeout: ## sec
BatTemp: ## F
BatVolt: #### mV
SoVolt: #### mV
SoCurr: #### mA
Serial: ##########
CONTROLLER STATUS
Timeout: ## sec
BatTemp: ## F
BatVolt: #### mV
CONTROLLER STATUS
Timeout: ## sec
BatTemp: ## F
BatVolt: #### mV
>
CONTROLLER STATUS
Timeout: ## sec
BatTemp: ## F
BatVolt: #### mV
>
>
CONTROLLER STATUS
BatTemp: ## F
BatVolt: #### mV
SoVolt: #### mV
CONTROLLER STATUS
BatVolt: #### mV
SoVolt: #### mV
SoCurr: #### mA
>
CONTROLLER STATUS
SoVolt: #### mV
SoCurr: #### mA
Serial: ##########
1
2
3
4
5
6
Figure 13
CONTROLLER STATUS
Timeout: ## sec
BatTemp: ## F
BatVolt: #### mV
SoVolt: #### mV
SoCurr: #### mA
Serial: ##########
CONTROLLER STATUS
Timeout: ## sec
BatTemp: ## F
BatVolt: #### mV
CONTROLLER STATUS
Timeout: ## sec
BatTemp: ## F
BatVolt: #### mV
>
CONTROLLER STATUS
Timeout: ## sec
BatTemp: ## F
BatVolt: #### mV
>
>
CONTROLLER STATUS
BatTemp: ## F
BatVolt: #### mV
SoVolt: #### mV
CONTROLLER STATUS
BatVolt: #### mV
SoVolt: #### mV
SoCurr: #### mA
>
CONTROLLER STATUS
SoVolt: #### mV
SoCurr: #### mA
Serial: ##########
1
2
3
4
5
6
Figure 11
MAIN MENU
3) Radio Setup
4) Legacy Control
5) Site Survey
>
MAIN MENU
2) Radio Status
3) Radio Setup
4) Legacy Control>
MAIN MENU
1) Controller Status
2) Radio Status
3) Radio Setup
4) Legacy Control
5) Site Survey
MAIN MENU
1) Controller Status
2) Radio Status
3) Radio Setup
>
MAIN MENU
0) Quick Setup
1) Controller Status
2) Radio Status
3) Radio Setup
>
>
MAIN MENU
1) Controller Status
2) Radio Status
3) Radio Setup
LCD Screen Icons
Selected and Saved
Saved Value
Selected
>
*
->
1
2
3
4
5
6
