Page 8
550 ASSEMBLY SECTION
42Τ ΧL Tail Drive Gear Set
42Τ ΧL 尾传动齿 轮组
Main Shaft Ring
主轴顶圈
Flybar
les
s S
y
s
te
m
无平
衡翼
系
统
Signal Line Set
信号线组
Signal Line Set
信号线组
Power Balance Cable
Reserve Port
电源 平 衡 线 预留口
Anti-Static Line
防静电线
Anti-Static Line
防静电线
Signal Line Set
信号线组
Servo Wiring scheme
舵机布线
Please insert the signal line of the body
according to the instructions:
Signal line (brown,red,yellow) →－+R
Signal line ( black ,red, white ) →－+S
机身 预埋信 号线请按 照指示 来插:
信号 线(棕.红.黄)→－+R
信号 线(黑.红.白)→－+S
W
D40
One-way Bearing Mount
单向轴承 座
Socket Screw
内六角螺 丝
Μ2.5Χ5mm
CNC 153T M0.7 Slant Thread
Main Deive Gear
CNC 153T M0.7 斜主传动齿 轮
