Tascam US-600 - 9 - Specifications; AD;DA Audio Converter Specs; Analog Input and Output Specifications; Headphone and Digital I;O Specs

TASCAM US-600 31
AD/DA audio converter
Sampling frequency
44.1/48/88.2/96 kHz
Quantization bit rate
24-bit
Analog audio inputs
Microphone inputs (MIC IN 1-4)
Balanced
Connectors: XLR-3-31 (1: GND, 2: HOT, 3:
COLD)
Input impedance: 2.2 kΩ
Nominal input level: –14 dBu (0.15 Vrms)
Minimum input level: –57 dBu (0.001 Vrms)
Maximum input level: +2 dBu (0.98 Vrms)
Line inputs (LINE IN 2-4)
Balanced
Connectors:
6.3-mm (1/4”) TRS phone jacks (Tip: HOT,
Ring: COLD, Sleeve: GND)
Input impedance: 15 kΩ
Nominal input level: +4 dBu (1.23 Vrms)
Minimum input level: –39 dBu (0.008 Vrms)
Maximum input level: +20 dBu (7.75 Vrms)
Instrument input (INST IN 1)
Unbalanced
Connectors: 6.3-mm (1/4”) TS phone jacks
(Tip: HOT, Sleeve: GND)
Input impedance: 1 MΩ
Nominal input level: –13 dBV (0.22 Vrms)
Minimum input level: –56 dBV (0.001 Vrms)
Maximum input level: +3 dBV (1.41 Vrms)
Analog audio outputs
Line outputs (LINE OUT 1-2)
Unbalanced
Connectors: RCA pin jacks
Output impedance: 200Ω
Nominal output level: –10 dBV (0.316 Vrms)
Maximum output level: +6 dBV (2 Vrms)
Headphones outputs (PHONES)
Connectors:
6.3-mm (1/4”) stereo phone jack
Maximum output: 49 mW + 49 mW (1 kHz,
0.1%, 32Ω)
Digital audio inputs
COAXIAL (DIGITAL IN)
Connector: RCA pin jack
Format: IEC 60958-3 (S/PDIF)
Digital audio outputs
COAXIAL (DIGITAL OUT)
Connector: RCA pin jack
Format: IEC 60958-3 (S/PDIF) or professional
IEC 60958 (AES/EBU) set using the software
control panel
9 – Specifications
