TASKalfa 3011i - Page 526

To Next Page

To Previous Page

10-45

Troubleshooting > Clearing Paper Jams

Pull Cassette 2 out toward you until it stops.

Remove any jammed paper.

Push Right Cover 2 and Cassette 2 back in.

NOTE

The cassette can be removed.
