TASKalfa 3011i - Page 547

To Next Page

To Previous Page

10-66

Troubleshooting > Clearing Paper Jams

Open reverse unit (C2) and remove any jammed paper.

Turn dial (C1) to remove any jammed paper.

Return the cover to the original position.
