Model 342 Tim Hortons Operating Procedures
150126
Step 10
Insert the ice buster through the door spout and into
the slot located just above the lower o-ring on the
draw valve.
Figure 15
Step 11
With the ice buster in place, rotate the draw valve to
allow installation of the draw handle. This will lock
the ice buster in place. Install the draw handle pin
and close the draw valve by moving the handle to
the left.
Figure 16
Step 12
Place the o-ring onto the prime plug and lubricate.
Figure 17
Step 13
Screw the prime plug into position on the front of the
door.
Figure 18
