6
Introduction
Models 340/341/342
130819
Model 342 Specifications
Freezing Cylinder
T wo, 7 quart (6.6 liter) capacity.
Mix Hopper
T wo, 20 quart (18.9 liter) capacity.
Beater Motor
T wo, .25 hp. motor .
Refrigeration Unit
T wo, approximately 7,500 btu/hr compressors.
Refrigerant 404A.
Electrical
Electrical
Two dedicated connections.
Maximum
Fuse Size
Minimum
Circuit Ampacity
Electrical Left Right Left Right
115/60/1 Air 30 25 25 17
208- 230/60/1 Air 20 15 15 11
208- 230/60/1 Water 15 15 12 11
208- 230/60/3 Air 15 15 12 11
220- 240/50/1 Air 15 12 13 9
380- 415/50/3N~Air 10 6 9 5
For exact electrical information, always refer to the
data label of the unit.
Air Cooled
Clearance: Minimum 3” (76 mm) around all sides. A
deflector is provided to prevent recirculation of warm
air.
Water Cooled
W ater inlet and drain connections under side of base
1/2” FPT.
Dimensions
Width: 26- 1/16 (662 mm)
Depth: 33- 1/8” (841 mm)
Height: 59- 7/8 (1521 mm)
Floor Clearance: 7- 1/2” (191 mm) mounted on
standard casters.
Approximate Weights
Net: 519 lbs. (235.4 kgs.)
Crated: 593 lbs. (268.9 kgs)
Volume: 48.9 cu. ft. (1.38 cu. m.)
Specifications are subject to change without notice.
This unit is designed and constructed to meet stringent
safety and sanitation requirements for NSF, UL, and
CSA.
