5
Models 340/341/342
Introduction
Model 341 Specifications
Freezing Cylinder
One, 7 quart (6.6 liter) capacity.
Mix Hopper
One, 20 qt. (18.9 liter) capacity.
Beater Motor
One, .25 hp. motor.
Refrigeration Unit
One, approximately 7,500 btu/hr compressor.
Refrigerant 404A.
Electrical
Electrical
One dedicated connection.
Maximum
Fuse Size
Minimum
Circuit Ampacity
115/60/1 Air 40 29
115/60/1 Water 30 22
208--230/60/1 Air 20 16
208--230/60/3 Air 15 13
220--240/50/1 Air 15 13
380--415/50/3N~Air 10 9
For exact electrical information, always refer to the
data label of the unit.
Air Cooled
Clearance: 3” (76 mm) around all sides. A deflector
has been added to the underside.
Water Cooled
W ater inlet and drain connections under side of base
3/8” FPT.
Dimensions
Width: 18--7/16” (468 mm)
Depth: 30” (762 mm)
Height: 59--7/8” (1521 mm)
Counter Clearance: 7--1/2” (191 mm) mounted on
standard legs.
Approximate Weights
Net: 393 lbs. (178.3 kgs.)
Crated: 458lbs. (207.8 kgs), 35.4 cu. ft. (.99 cu. m.)
Specifications are subject to change without notice.
This unit is designed and constructed to meet stringent
safety and sanitation requirements for NSF, UL, and
CSA.
