Taylor C722 - Model C722 Exploded View Parts Identification

4-2
OPERATOR PARTS IDENTIFICATION
Model C722
Operator Parts Identification
4
Model C722 Exploded View Parts Identification
*Factory-equipped agitator units only
**Optional Feed Tube
Item Description Part No.
1 Kit A.-Hopper CVR 14 QT BLA X69146
**2 Orifice 022465-100
**3 O-ring-11/16 OD X .103W Red 016132
**4 Tube A.-Feed-SS-5/32 Hole X29429-2
**5 O-ring-.643 OD X .077W 018572
6 Panel-Rear 080162
7 Panel A.-Side Right X68854
8 Panel A.-Front X81843
9 Screw-1/4-20X3/8 Slotted 011694
10 Panel A.-Front-Lower X81841
11 Shelf-Drip Tray 080782
12 Tray-Drip 080781
Item Description Part No.
13 Shield-Splash-Wire 046177-SP
14 Pan A.-Drip 15 1/8 Long X51601
15 Stud-Nose Cone 055987
16 Panel-Side Left 068851
17 Filter A. X81440
17A Filter-Air-18.28X15.5X.70 052779-15
18 Cover-Access-Front-R. 056933
19 Screw-10x3/8 Slotted Hex 015582
20 Cover-Access-Left 081834
21 Pan-Drip-Rear 080226
*22 Blade A.-Agitator X56591-SP
