22
Controls, Systems and Operations
Model C723
The SYSTEM INFORMATION is displayed on three
separate screens. The first screen contains the
control and software version installed in the
machine. (See Figure 32.)
SOFTWARE VERSION
C723 CONTROL UVC4
VERSION V00.00.000
> Next
Figure 32
Press the SEL key to advance to the next system
information screen containing the software language
version. (See Figure 33.)
Language
V3.00 English
> Next
Figure 33
Press the SEL key to advance to the third system
information screen containing the model bill of
material and machine serial number. Pressing the
SEL key again will return to the Manager's Menu.
(See Figure 34.)
B.O.M. C700000000
S/N K0000000
> Next
Figure 34
The CURRENT CONDITIONS screen displays the
current viscosity, the hopper temperature and the
barrel temperature. Press the SEL or MENU keys to
return to the Manager's Menu. (See Figure 35.)
VISC 0.0 0.0
HOPPER 41.0 41.0
BARREL 41.0 41.0
Figure 35
The NET SERVICE PIN screens allows the
manager to initialize a network connection for
networking kitchens. (See Figure 36.)
NET SERVICE PIN
ARE YOU SURE?
Yes
> No
Figure 36
Use the arrow keys to move the arrow up or down.
Pressing the SEL key with the arrow next to “No” will
return to the Manager's Menu. Pressing the SEL key
with the arrow next to “Yes” will connect to the
network if a gateway card is connected.
Note: If “Yes” is selected, it may take a few
moments for the memory to clear and the defaults to
load. The display may show the message
“COMMUNICATIONS FAILURE” during this time.
