Taylor C852 - C850;C852 Left Side View

11
C850/C852 Left Side View
Figure-4 (C850 shown)
Item Part No. Description Qty. Function
Warr.
Class
1 X85715 Handle A.-Align Ring 1 (C850)
2 (C852)
The handle clicks in to the platen latch
when in the down position.
