16
C854/C856 Right Side View
Figure-7 (C854
with outrigger
shown)
Item
Part No.
Description
Qty.
Function
Warr.
Class
1
X8571
6
Handle A.-Align Ring
1 (C854)
2 (C856)
The handle clicks in to the platen latch
when in the down
position.
103
1
15
17
