C850 Exploded View
Item Part No. Description Qty. Function
Warr.
Class
1 X84969 Can A.-Grease-L 1 Container for grease. 103
2 X84224 Shroud-Upper Side 1 Metal bracket that the grease can slides
into, securing it next to the lower grill plate.
103
3 X84325 Shroud A. - Lower - Left 2 Left/right access panel. 103
4 070695 Screw-10-32X1/2 Phil 4 Fastens bumpers to panels. 000
5 084549 Bumper 2 Protects grill from damage. 000
6 X73600-SER Kit A.-Grease Shield 2 Fastens grease shields to rear shroud. 000
7 082959 Panel-Rear 1 Provides access to internal components for
service and cleaning.
103
8 024298 Screw-10-32X3/8 Phil 34 Secures the panel to the frame. 000
9 X84225 Shroud A.-Upper -Right 1 Metal bracket that the grease can slides
into, securing it next to the lower grill plate.
103
10 X84608 Can A.-Grease-R 1 Container for grease. 103
11 027408 Screw-10-32X1/4 SLTD Truss Secures the panels to the frame.
12 082958 Panel-Side-Right 1 Provides access to internal components for
service and cleaning.
103
13 078377-1 Caster-5 7-5/8 Stem 2 Allows grill mobility. 103
14 086984-1 Outrigger A.-Right 1 Stabilizes grill. 000
15 087002 Pin-Cotter 1/8 x 1 in. 8 Secures the outrigger to the caster. 000
16 073240-3 Caster-5 7-5/8 Stem-Swivel w/
Lock
2 Prevents grill movement when the brake is
used.
103
17 086985-1 Outrigger-Left 1 Stabilizes grill. 000
18 076989-WP Switch-Rocker- DPST 10A 1 Activates power to the grill and the exhaust
fans.
103
19 X84230 Door A.-Control 1 Houses the controls. 103
20 X85623-SER Touchscreen A. 1 Controls all functions of the grill. - - -
21 068583 Cover A.-USB Waterproof 1 Protects USB port from water damage. 103
22 076012 Button-Operator-Black 1 Activates the Cook cycle, keeps the upper
platen in the closed position, and displays
STANDBY on the control. When pressed
twice with 1-second intervals between
presses, the upper platen will automatically
lower into the Standby position.
000
23 076011 Button-Operator-
Red
1 Cancels Standby mode, raises the upper
platen, and deactivates the Cook cycle.
000
24 X85465 Shield A.-Rear GRS 1 Prevents grease migration. 000
25 082957 Panel-Side-Left 1 Provides access to internal components for
service and cleaning.
103
26 085447 Spacer Bumper 1 Protects grill from damage. 000
27 084613 Bumper 1 Protects grill from damage. 000
