* See Taylor Warranty Card
+ Available Separately
48
Parts L ist Models QS12/QS24
060102
DESCRIPTION PARTS
UPDATE
REMARKSWARR.
CLASS
QTY.
QS24
QTY.
QS12
PART
NUMBER
FILTER--CORCOM 2VR1 032567 1 2 103 Prior to J9054573 143
GASKET --BOX A. 074060 1 2 000 J9054573/up 143
HARNESS--WIRE REMOTE *QS24* 078614 1 2 103
PAD A. --KEY REMOTE *QS24* X78573 1 2 103
PCB A. -- REMOTE GRILL X50412--SER 1 2 212 J6041233/up
CHIP--SOFTWARE QSDSP CONTROL X40908 1 2 103
PCB A. -- REMOTE GRILL J6041232/prior -- update with X50412--SER PCB A.
& X74320--SER decal
SWITCH--MEMBRANE--5 POSITION--8”L 044520 1 2 103
BRACKET --FRONT TRAY *QS12* 079272 1 103
BRACKET --FRONT TRAY *QS24* 078527 1 103
BRUSH--.625X1.500 QS12/24 074166 1 1 000 J9110000/up 147
CLEANER--SIZZLE #545A 079896 1 1 000 Case of 6 Qts. W/Spray bottle
CONTROL--HI LIMIT--475F 078410 3 6 103
CONNECTOR--MATE LOK 6 CIR--PIN 028594 2 4 103
+PIN--MALE .084”DIA--MATE--N--LOK 021624 3 6 103
CORD A. --POWER X79291 1 103
CORD A. --POWER X79877 1 103 Grooved platen only
COVER A. --PLATEN *QS24* X78798 1 1 103
COVER A. --REAR *QS12* X79444 1 103
COVER A. --REAR *QS24* X74332 1 103 Replaces X79423
COVER--LINKAGE *QS24* 079441 1 103
CYLINDER--GAS DUEL SEAL QS24 074313 2 2 103 Replaces 079215
DECAL A. --KEYPAD QS SERIES X74320--SER 1 1 000 Green (Replaces Old Red Decal -- 078612)
+BUMPER--.500 DIA X .090 THK 079499 1 000
DECAL --MIN CLEARANCE *QS24* 079061 1 1 000
DECAL --TERMINAL BLOCK --LEFT 079046--23L 1 000
DECAL --TERMINAL BLOCK--RIGHT 079046--23R 1 000
DIAGRAM--WIRING 074063-- 1 1 000 J9054573/up 143
DIAGRAM--WIRING 079691-- 1 1 000 J7100000 TO J9054573 122
DIAGRAM--WIRING 078807-- 1 1 000 Prior to J7100000 122
GASKET --ACCESS COVER 074059 1 000 J9054573/up 143
HARNESS--CONTROL TO REMOTE QS24 078618 1 2 103 Cntrl board to remote keypad box
To Next Page
