49
Models QS12/QS24
Parts L ist
* See Taylor Warranty Card
+ Available Separately
DESCRIPTION PARTS
UPDATE
REMARKSWARR.
CLASS
QTY.
QS24
QTY.
QS12
PART
NUMBER
HARNESS--T/C LOWER *QS12* 079292 1 103 Thermocouples (6 lower cooking zones) replace
w/074178 -- T/C lower front QS, 074179 -- T/C
lower middle QS, 074180 -- T/C lower rear QS as
req’d or all 3 to replace harness
153
HARNESS--T/C LOWER *QS24* 078643 1 103 Same as above 153
HARNESS--T/C UPPER #4 078622--4 1 1 103 Thermocouples (upper platen assembly)
HARNESS--T/C UPPER #5 078622--5 1 1 103 Thermocouples (upper platen assembly)
HARNESS--T/C UPPER #6 078622--6 1 1 103 Thermocouples (upper platen assembly)
HARNESS--WIRE--LOWER POWER 074006 1 2 103 J9054573/up 143
+CONNECTOR--HOUSING 3 PIN 078596 1 2 103
HARNESS--WIRE--LOWER POWER (OLD) 078620 1 2 103 Power switch to interface board (prior to J9054573) 143
HARNESS--WIRE--UPPER POWER 074007 1 1 103 1 per upper platen
HEAT ER--CAST -- 1800 WATT 079639-- 3 6 103 J7100000/up 122
HEAT ER--CAST -- 1400 WATT 078409-- 3 6 103 Prior to J7100000 122
KIT A.--T--HANDLE *QS12 --QS24* X74326--KIT 1 1 103
+WASHER 078638 1 1 000
KIT A.--RELAY BOX A. (60HZ--OLD) X79897--SER 103 Use X74036 --SER 135/143
LABEL --CAUTION--HOT SYMBOL 075717--SYM 1 1 000 J9080000 to K0100000
LABEL --PRODUCT 079714 1 1 000
LABEL --PRODUCT STOP BULLS EYE 079894 1 000 Grooved platen only
LABEL --WARN--NO SPRAY SURFACE--SYM 074148--SYM 1 2 000 J9110000/up
LEG--4”--3/8--16 STUD 036397 4 4 103
MAN--OPER QS24 050559--M 1 1 000
PANEL A.--CONTROL *QS12* X79265 1 103
PANEL A.--CONTROL *QS24* X78405 1 103
PANEL A.-- SIDE LEFT NONE N/A for replacement--sealed unit to prevent grease
migration
PANEL A.--SIDE RIGHT NONE
PANEL--REAR *QS12* 079280 1 103
PANEL--REAR *QS24* 079044 1 103
PARTITION A.--GREASE X79944 1 1 103 Replaces X78402 137
GASKET --GREASE PARTITION 074154 1 1 000 J9101783/Up (Can adapt to existing models) 147
PIN--LOCAT ING 078544 4 4 103
PIVOT A.--PLATEN COMPLETE *QS24 X78758--SER 1 1 103
