Taylor QS12 Service Manual

* See Taylor Warranty Card
+ Available Separately
50
Parts L ist Models QS12/QS24
DESCRIPTION PARTS
UPDATE
REMARKSWARR.
CLASS
QTY.
QS24
QTY.
QS12
PART
NUMBER
ARM--PLATEN *QS24* 078520 2 2 103 ARM--PLATEN LINKAGE *QS24* 079192 2 2 103 BEARING--CYL MOUNT *QS24* 079214 2 2 103 BEARING--L INKAGE ARM *QS24* 079213 2 2 103 BEARING--OPEN END NEEDLE *Q524* 078522 8 8 103 BEARING--OPEN END NEEDLE *Q524* 078523 2 2 103 BEARING--OPEN END NEEDLE *QS24* 078652 2 2 103 BEARING--PLATEN ARM PIVOT QS24 078541 2 2 103 CAP--BEARING PLATEN ARM *QS24* 078548 2 2 103 CYLINDER--GAS DUEL SEAL QS24 074313 2 2 103 Replaces 079215 E--RING 3/4 077046 4 4 000 E--RING 3/8 038958 16 16 000 E--RING EXTERNAL 1/2 024908 16 16 000 HANDLE--PLATEN LIFT *QS24* 078592 1 1 103 LINKAGE--PIVOT UPPER *QS24* 078760 2 2 103 MOUNT --CYLINDER LIFT *QS24* 079193 1 1 103 PIN--LINKAGE ARM *QS24* 078664 2 2 103 PIVOT A.--PLATEN *QS24* X78759 1 1 103 PIVOT--PLATEN ARM *QS24* 078556 2 2 103 PLAT E--PLATED LINKAGE PIVOT LH 078560 1 1 103 PLATE --PLATED LINKAGE PIVOT RH 078559 1 1 103 RETAINER--BEARING *QS24* 079191 2 2 103 ROD--LINKAGE 3/4 DIA *QS24* 079216 1 1 103 Rod w/gear unit ROD--PLATEN LINKAGE MID *QS24 079194 1 1 103 ROD--PLATEN LINKAGE MID *QS24* 078549 1 1 103 ROD--PLATEN LINKAGE UPPER *QS24 078550 1 1 103
PLATEN ASSEMBLY 208V 1400W X79629--23 1 1 212 208V -- 60HZ 123 PLATEN ASSEMBLY 208/230V 1400W X79629 --33 1 1 212 208 --230V -- 60HZ 123 SCRAPER--TEFLON WIPER 075887 1 1 000 SCRAPER--TROUGH 079726 1 1 000 SCREW--10--32X1/2 THUMB STAINLES 078651 2 2 103 Thumb screws SHEET --SEAMED RELEASE *QS24* 078804 2 2 000 SHIELD--GREASE FRONT *QS24* 079433 1 1 103

Taylor QS12 Specifications

General

Brand	Taylor
Model	QS12
Category	Grill
Language	English
