51
Models QS12/QS24
Parts L ist
* See Taylor Warranty Card
+ Available Separately
DESCRIPTION PARTS
UPDATE
REMARKSWARR.
CLASS
QTY.
QS24
QTY.
QS12
PART
NUMBER
SHIELD--GREASE REAR *QS24* 079434 1 1 103
SLIDE A.--GAP -- FRONT X78864--F 1 1 103 1 per platen
PIN--GAP--SLIDE--ADJ. 078789 2 2 103
SCREW--1/4--20X1/4 ALLEN SET 001801 2 2 000
SCREW--10--24 X 3/8 SET SS 078863 2 2 000 Prior to J8020000
SLIDE A.--GAP -- REAR X78864--R 1 1 103 1 per platen
PIN--GAP--SLIDE--ADJ. 078789 2 2 103
SCREW--1/4--20X1/4 ALLEN SET 001801 2 000
SCREW--10--24 X 3/8 SET SS 078863 2 2 000 Prior to J8020000
SPRING .375 OD X .037 X 1.500 079704 2 2 103 Release bar (Replaces 078805) 125
SPRING--3/16 BELLEVILLE DISC 079127 2 2 103 Prior to J7010000
STANDOFF --FRONT 079289 4 103
STANDOFF --REAR 079288 2 103
SWITCH--ROCKER SPST OFF --ON 078418 1 2 103 Power
TRANS.--CONT. --40VA 120/200/240V 045754 1 2 103
TRAY A. --GREASE *QS24* X79940--SER 1 1 103 Replaces X78428 137
T/C LOWER FRONT QS 074178 1 1 103 Thermocouple -- replaces 079292 or 078643
harness
T/C LOWER MIDDLE QS 074179 1 1 103 (Same as above)
T/C LOWER REAR QS 074180 1 1 103 (Same as above)
VIDEO--TRAIN QS12 & QS24 OPERATIONS 051170--V 1 1 000
WIPER--SIDE LEFT *QS24* 079437 1 1 103
WIPER--SIDE RIGHT *QS24* 079438 1 1 103
WIPER--FRONT *QS24* 079439 1 1 103
WIPER--REAR *QS24* 079440 1 1 103
ACCESSORIES:
SCRAPER A. --GROOVE -- RUBBER X79246 1 1 103 Rubber -- for grooved platen
SCRAPER A. --GROOVE --METAL X79668 1 1 103 Metal -- for grooved platen
