Taylor QS12 Service Manual

* See Taylor Warranty Card
+ Available Separately
52
Parts L ist Models QS12/QS24
060102
DESCRIPTION PARTS
UPDATE
REMARKSWARR.
CLASS
QTY.
QS24
QTY.
QS12
PART
NUMBER
OPTIONS: CART--SEE BREAKDOWN
BRACKET A. --LEG SUPPORT X79994 4 103 CASTER--SWIVEL 3/4--10 021279 2 2 103 CASTER--LOCKING 3/4--10 030307 2 2 103 LEG--INSERT 079990 4 4 103 PIN--LEG HEIGHT 079991 4 4 103
KIT A.--PRODUCT STOP X79916 1 1 103 KIT A.--REAR COVER STOP BAR X79689 1 103 Hood stop KIT A.--REAR COVER STOP BAR X79873 1 103 Hood stop -- 2 platens KIT A.--REAR COVER STOP BAR LH X79900 1 103 Hood stop -- left platen KIT A.--REAR COVER STOP BAR RH X79902 1 103 Hood stop -- right platen LEG--2--1/2 IN 3/8--16 STUD 079715 4 4 103 Discontinued 50HZ BOX A. --RELAY (OLD) X79678--75 1 2 212 50HZ & 60HZ use X74036--SER 143
RELAY--SPST--200/240VAC (OLD) 079690 6 6 103
BLOCK--TERMINAL--5P SCREW W/JUMPERS X79839--62R 1 103 Right side -- J8050000/UP BLOCK--TERMINAL--5P SCREW 079045--62R 1 103 Right side -- prior to J8050000 DECAL --SWITCH *QS24* SYMBOL 079454 1 2 000 DECAL --TERMINAL BLOCK *QS24 079046--62L 1 000 DECAL --TERMINAL BLOCK *QS24 079046--62R 1 000 CONTROL --HI--LIMIT 550F NO RESET 074165 12 12 103 K0010000/ up (For units prior to K0010000, see
Parts Update 150.)
150
DIAGRAM--WIRING (NEW) 074063--75 1 1 000 J9054573/up 143 DIAGRAM--WIRING (OLD) 079691--75 1 1 000 FILTER A.--*M22* X79163 1 1 103 HARNESS--POWER LOWER *QS24* (NEW) 074065 1 2 103 J9054573/up HARNESS--POWER LOWER *QS24* (OLD) 079496 1 2 103 HARNESS--POWER UPPER (NEW) 074007 1 1 103 1 per platen (replaces 079497) HEATER--CAST 230V 1800W *QS24* 079639--26 3 6 103 PLATEN ASSEMBLY 230/400V 1400W X79629--75 1 1 212 230/400V -- 50HZ 123 VIDEO--TRAIN QS24 OPS 051170 --PAL 1 1 000
