TBB NEMO Series User Manual

NEMO series battery to battery Charger
8
4. Preparation and Configuration
4.1 Material list
The unit is supplied with the following materials. Please confirm the serial number on charger
is same to that on outer carton.
 NEMO battery to battery charger.
 User manual.
 Sensor / Ignition / RS485 (model dependent for IDX and IDDX).
4.2 Location
Please install the equipment in a clean, cool location with good ventilation.
 Working temperature: -20℃~+60℃.
 Storage temperature: -40℃~+85℃.
4.3 Battery type setting
Table 4-1 Switch status for battery type and charging voltage
Switch status Battery type
Charging Voltage (V)
Absorption Floating
12V 24V 12V 24V
OFF, OFF AGM 14.6 29.2 13.5 27
OFF, ON GEL 14.2 28.4 13.8 27.6
ON, OFF LFP 14.4 28.8 13.5 27
ON, ON WET 14.8 29.6 13.8 27.6
