TBB NEMO Series User Manual

NEMO series battery to battery Charger
9
4.4 Wiring and Fuse recommendation
Please find the following recommended cable size and fuse rating.
We recommend that a fuse is installed on the input and output of the Nemo closest to the
battery.
 Fuse recommendation
Table 4-2 Fuse recommendation
Model
Input Output
Max
current
fuse
Max
current
fuse
DX1230, DDX1230, IDX1230,IDDX1230 40A 50A 30A 40A
DX1215, IDX1215, DX2415, DDX2415,
IDX2415, IDDX2415
20A 25A 15A 20A
DX2415L, DDX2415L, IDX2415L, IDDX2415L 40A 50A 15A 20A
 Wiring recommendation
Table 4-3 Input wiring recommendation
Model
Recommended wiring
1m 2m 5m 10m
DX1230,DDX1230,IDX1230,IDDX1230
DX2415L,DDX2415L,IDX2415L,
IDDX2415L
6mm
2
or
AWG9
10mm
2
or
AWG7
16mm
2
or
AWG5
25mm
2
or
AWG3
DX1215, IDX1215, DX2415, DDX2415,
IDX2415, IDDX2415
4mm
2
or
AWG11
6mm
2
or
AWG9
10mm
2
or
AWG7
16mm
2
or
AWG5
Table 4-4 Output wiring recommendation

TBB NEMO Series Specifications

General

Brand	TBB
Model	NEMO Series
Category	Battery Charger
Language	English
