NEMO series battery to battery Charger
14
6. Operation
6.1 Double check
Before operation, please ensure the following steps are ensured.
 The battery voltage matches the charger model.
 Polarity of cable connection is correct.
 Voltage sensor is installed on the positive terminal of battery.
 Ignition wire is connected for Euro 6 vehicles.
6.2 LED Description
6.2.1 For DX and IDX series
Figure6-1 Front panel of LED indication for DX and IDX series
6.2.2 For DDX and IDDX series
Figure 6-2 Front panel of LED indication for DDX and IDDX series
