NEMO series battery to battery Charge
r
13
For IDX and IDDX models, RS485 cable can be connected to a PC monitor or a controller
to view some working information of the charger
. The R
S485 protocol can be
obtained
from our sales team if needed, please contact your local distributor
.
M
on
ito
r
RS48
5
A+
（
Red
）
RS48
5
B-
（
Bl
ac
k
）
RS48
5
Figure 5-3 Connecting diagram of the RS485 cable
17
19
