NEMO series battery to battery Charger
11
When installing this unit on Euro6 vehicle with variable voltage “smart
alternator”, please connect IGN wire.
For safety, please always connect ground (NEG.-) first and then connect the Aux battery
positive, starter battery positive and PV positive respectively.
1) Connect battery negative. Connect the negative power cable to the battery to battery
charger and connect the other end of negative cable to main battery negative terminal
or directly to the chassis, ensuring a good solid electrical connection.
2) Connect the auxiliary battery. Connect the positive power cable between terminals
marked OUT+ on battery to battery charger and the auxiliary battery positive terminal.
Ensure the in-line fuse is removed prior to connecting the cable and inserted afterwards.
3) Connect the starter battery. Connect the positive power cable between terminals marked
ALT+ on battery to battery charger and the starter battery positive terminal. Ensure the
in-line fuse is removed prior to connecting the cable and inserted afterwards.
4) Connect the PV. Connect the positive power cable between terminals marked PV+ on
battery to battery charger and the PV positive cable. Ensure the in-line fuse is removed
prior to connecting the cable and inserted afterwards.
5) Connect the ignition wire.
6) Connect the battery sensor.
7) Connect the RS485 communication cable (model dependent RS484 also used for
programming IDX/IDDX).
The MAX VOC PV input is 25VDC for 12V models and 50VDC for 24V
models(open circuit voltage).
Please double check the solar panel you are going to install matching the
maximum voltage of PV input.
