TC-Helicon Voicelive 2

Specifications
103
Analog Inputs
Connectors, balanced Mic.: XLR, Line: 1/4” phone jack,
Guitar: 1/4” phone jack, Aux: 1/8”
stereo mini jack
Input Impedance: Bal./Unbal. Mic.: 2.14/1.07 kOhm,
Line: 13/6.5 kOhm
Mic Input Level @ 0 dBFS -49dBu to +10dBu
Line Input Level @ -37 dBu to +22 dBu -37 dBu to +22 dBu
EIN @ Max Mic Gain Rg = 150 Ohm -126 dBu
Mic/Line Input SNR > 107 dB
Guitar Input impedance 1 MOhm
Guitar Input Level @ 0 dBFS 14 dBu to -4 dBu
Guitar Input SNR >104dB
Aux Input Level @ 0dBu +2dBu
A to D Conversion 24 bit, 128 x oversampling bit
stream via S/PDIF, 16 bit via
USB, 110dB SNR A-weighted.
Analog Outputs
D to A Conversion 24 bit, 128 x oversampling bit
stream via S/PDIF, 16 bit via
USB, 115dB SNR A-weighted
Connectors, balanced XLR and 1/4” phone jack
Output Impedance Bal./ Unbal. 100/50 Ohm
Output Range (Line/Mic Level) 16 dBu / 0dBu
Dynamic Range > 109 dB, 20 Hz to 20 kHz
Frequency Response +0/-0.3 dB, 20 Hz to 20 kHz
Headphone Out 1/8” Mini stereo jack, 32 Ohm,
+16dBu max (180mW max)
Digital Inputs and Outputs
Connectors RCA Phono (S/PDIF)
Formats S/PDIF (24 bit), EIAJ CP-340,
IEC 958
Sample Rates 44.1 kHz, 48 kHz,88.2kHz, 96kHz
EMC
Complies with EN 55103-1 and EN 55103-2
FCC part 15, Class B, CISPR 22,
Class B
Safety
Certified to IEC 65, EN 60065, UL6500
and CSA
Environment
Operating Temperature 32° F to 122° F (0° C to 50° C)
Storage Temperature -22° F to 167° F (-30° C to 70° C)
Humidity Max. 90 % non-condensing
Control Interface
USB USB-B
MIDI In/Out/Thru: 5 Pin DIN
Pedal 1/4” TRS phone jack
Supplementary
Display 192 x 64 Blue STN LCD, White
Back light
Dimensions 13.8” x 3” x 8.5” (350 x 76 x 216)
Weight 5 lb. (2.3 kg)
External Power Supply Mains Voltage 100 to 240 VAC, 50 to 60 Hz
(auto-select)
Power Consumption <14 W
Technical specifications are subject to change without notice
