TC-Helicon Voicelive 2 User Manual

THRESHOLD (MANUAL Gate Only)
This parameter becomes visible when the GATE has
been switched to MANUAL. The THRESHOLD defines
the minimum singing level you need to reach in order for
the Gate to open and let your voice sound. The factory
default setting of -40 dB is very sensitive to allow a wide
range of singing levels but it may also allow more nearby
instrumental sounds through when you are not singing.
In this case, further adjustment from -39 dB and upward
may be needed.
The Global Controls: Tone
47

TC-Helicon Voicelive 2 Specifications

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Power

external power supply mains voltage	100 to 240 VAC, 50 to 60 Hz
power consumption	<14 W

Analog Inputs

mic input impedance	2.14/1.07 kOhm
line input impedance	13/6.5 kOhm
guitar input impedance	1 MOhm

Analog Outputs

output impedance	100/50 Ohm
output range	16 dBu / 0dBu
dynamic range	> 109 dB, 20 Hz to 20 kHz

Weight and Dimensions

dimensions	13.8" x 3" x 8.5" (350 x 76 x 216)
weight	5 lb. (2.3 kg)
