TC-Helicon Voicelive 2 User Manual

1/8 DOT 1/8 1/8 TRIP
1/16 DOT 1/16 1/16 TRIP
1/32 DOT 1/32 1/32 TRIP
SAMPLE LOOP CAPTURE
When set to START, you must press the Shortcut
button immediately before you sing. When set to END,
you can press the Shortcut button at the end of your
sung phrase.
SAMPLE DIRECTION
Samples can play forward or reverse. This effect is most
noticeable on longer duration samples.
PATH
When this is set to POST, the captured sample will
be a composite of all effects that were on when it was
captured. When set to PRE the sample is captured dry
but effects can be added and removed as the sample
continues to loop.
Additional Rhythmic Features
These features help you to co-ordinate the timing of
your singing with the rhythmic effects.
COWBELL
Turning this feature on produces a metronome-type
cowbell sound to give an audible indication of the
current tempo. This is also a possible SHORTCUT
parameter so you can access it live.
LEVEL
Volume control of the cowbell sound.
PATTERN AUDITION
Allows you to hear a tone playing when the TYPE is
set to a pattern. This allows you to hear the patterns
without singing.
Note that the COWBELL and PATTERN AUDITION
sounds are bussed into the Guitar audio path. As such,
they will not produce sound if
GUITAR MUTE in the I/O tab
in the Setup menu is on. A side benefit is that, if you’d
like to use the cowbell sound in performance, any effects
you select in the Guitar FX menu will be present on the
cowbell also.
The Edit Menu: RHYTHMIC Tab
81

TC-Helicon Voicelive 2 Specifications

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Power

external power supply mains voltage	100 to 240 VAC, 50 to 60 Hz
power consumption	<14 W

Analog Inputs

mic input impedance	2.14/1.07 kOhm
line input impedance	13/6.5 kOhm
guitar input impedance	1 MOhm

Analog Outputs

output impedance	100/50 Ohm
output range	16 dBu / 0dBu
dynamic range	> 109 dB, 20 Hz to 20 kHz

Weight and Dimensions

dimensions	13.8" x 3" x 8.5" (350 x 76 x 216)
weight	5 lb. (2.3 kg)
