HM10 Home AC Charger Mobile Application (APP) User Guide
4) If selected “repeat” in step (1), select the day in a week that you want this charging session
to apply. (E in Figure 6.2; this option will only be available if you select “repeat” on top)
Blue text means a day is selected, while white text represents not being selected.
After all parameters are set, click on “Create Schedule” button to create the charging schedule. (F
in Figure 6.2)
With the schedule set, the charger will automatically start charging at the set start time if it is
connected to an EV. It will stop charging at the set end time if it is still in a charging session. (If
the car’s battery becomes full before the set end time, the charging session will finish in advance.)
6.4 Set Maximum Charging Current
Although TCHARGE
®
HM10 charger has its own rated charging current output, for some locations
of installation, the electric circuit providing power input for the charger may not be able to handle
current of such volume.
In some other cases, you may want to limit the maximum charging current when using the charger
to protect the life span of your vehicle’s battery.
For these cases, you may want to set a maximum charging current output value for your
TCHARGE
®
HM10 charger.
To adjust your charger’s maximum charging current output through TCHARGE
®
home charging
APP, follow the instructions below.
1) Open my charger list from About me tab (Figure 6.3 left; also see Figure 4.2 on page 10
for reference).
2) Find the charger that you want to limit its charging current output, then click “Set current”
on the charger’s profile (A in Figure 6.3)
3) On the setting page (Figure 6.3 right), select the maximum current output value that you
want to apply to the charger (B in Figure 6.3).
4) Click on “Confirm” button to finish setting (C in Figure 6.3).
For maximum current setting, our system only accepts values that
are integers and fall within the range available in the drop-down menu
at this point. Set for an invalid value will not result in success.
Also, please note that a charger’s current output is always limited by
its hardware. Setting a number higher than a charger’s rated current
output value on the APP will not make the charger’s actual current
output exceeding its rated output.
