Table 13: PQvision Settings Menu
Determines if the unit’s PCB is ready to run
“Run” – PCB is calibrated and ready
If the system state is labeled as “Calibrate check” the user
must perform the calibration process. Follow calibration steps
in the debug section
This section can be used to enable and disable the status
detections conditions that drive the output relays. Upon power
up the relays energize, closing the normally open contacts.
This is the nominal status OK state. The output relays stay in
this state until one of the configured alerts is detected or the
board becomes unpowered.
After selecting desired relay outputs select save settings.
Allows the user to change Modbus settings of the App and
device.
When changing Modbus settings, the user will start with
selecting a new slave address/Baud rate/ and parity of the
Device. After selecting desired Modus settings of the device,
the user will select apply Modbus settings and save settings.
Afterwards the user will need to go to Menu and Reset
PQconnect. This will soft reboot the board.
Note: Changing Modbus settings of the device can only be
done through tech access
If the user would still like to use the PQvision application with
the updated Modbus settings, they would need to navigate to
the settings menu and apply the new Modbus settings for the
application.
By default, Input Relay 1 will be set to thermal switch and Input
Relay 2 is off. Relay 1 is intended to be used with the normally
closed thermal switch available on the filter reactor.
Note: Input Relay 1 is connected to J7 of the PCB and Input
Relay 2 is connected to J8.
Allows the user to change the filter rated voltage.
Note: The user should only select the voltage the filter is rated
for. Range 240V to 600V
